*This Unit is Available and Ready Today – In-Store Purchase Required*
Power & Battery
-
Battery: STAR® Smart Lithium, 105Ah
-
Motor: 4 kW AC with thermal protection
-
Controller: 48 V, 350 A
-
Charger: Onboard smart charger (compatible with lithium system)
Dimensions
-
Overall: 119” L × 51” W × 82.5” H (302 cm × 130 cm × 210 cm)
-
Wheelbase: 66” (168 cm)
-
Ground Clearance: 6.875” (17.46 cm)
-
Wheel Type: 14" × 7" (–43 mm offset) aluminum rims
-
Tire Size: 20×10R14 All Terrain
-
Tire Pressure: 20 psi (138 kPa)
Body & Chassis
-
Chassis: Welded tubular steel
-
Body: Plastic with automotive paint
-
Roof: Plastic, injection-molded
-
Side Rails: Aluminum
Battery Advantage – 105Ah STAR® Smart Lithium
-
Extended range compared to standard lead-acid batteries
-
Faster charging for reduced downtime
-
Maintenance-free operation, no watering required
-
Longer lifespan with thousands of charge cycles
-
Energy-efficient and environmentally friendly
Performance
-
Passengers: 4
-
Top Speed: 19.5 mph (25 mph if LSV)
-
Turning Radius: 10.5 ft (3.2 m)
-
Load Capacity: 800 lbs (363 kg)
-
Weight (with batteries): 1,255 lbs (569 kg)
-
Drive Train: Direct rear drive, 12.4:1 ratio
-
Brakes: 4-wheel hydraulic (front disc, rear drum) with foot-activated multi-click parking brake
Steering & Suspension
-
Steering Wheel: 3-spoke aluminum, self-canceling
-
Steering System: Self-compensated rack & pinion
-
Front Suspension: Adjustable coil-over shock, independent
-
Rear Suspension: Adjustable coil-over shock
