Serial Number: MBNMFL6DKRZC00734
Specifciations
|
ENGINE: Type: Naturally aspirated, water cooled, indirect injection diesel Engine HP [kW] @ RPM: 24.7 (18.4) @ 2500 Maximum Torque (in-lbs) @ RPM: 566 (64) @ 2000 Displacement (in3): 80.4 Number of Cylinders: 3 Firing Order: 1-3-2 Bore & Stroke (in): 3.1 x 3.6 Compression Ratio: 22:1 Low Idle RPM: 1030 High Idle RPM: 2700 Injection Pump: Denso in-line Accelerator : Hand throttle lever w/cruise knob Muffler: Under hood Air Cleaner: 4" dry Fuel: ULSD Fuel Tank gal (L): 9.3 (35) POWER TAKE OFF: Independent wet clutch PTO Operation: Push button Rear PTO RPM: 540 Mid PTO RPM: 2500 PTO HP [kW]: 17 (10.4) DASH INSTRUMENTS: SAFETY EQUIPMENT: |
DRIVE TRAIN: Transmission: HST three range Number of Speeds: Infinite Clutch: N/A Brakes: Single HYDRAULICS: Type: Open center Steering Pump Output gpm (L/min): 5 (19) Implement Pump Output gpm (L/min): 6.3 (23.8) 3-Point Hitch: Cat I with telescoping stabilizers Optional Fitments: One OPERATOR STATION: FRONT AXLE: |
ELECTRICAL: Battery: 630 CCA, 52 Ah Alternator: 55 A Starter Capacity: 1.6 kW Lights: Projector lamp & LED strip Gauges: Electronic hour meter, stepper gauge for RPM, LCD for temp & fuel DIMENSIONS: Tilt Steering: Yes Overall Length in (mm): 112.7 (2863) Overall Width in (mm): 54.4 (1383) Overall Height in (mm): 93.6 (2377 Wheelbase in (mm): 61.4 (1560) Turning Radius ft (m): 7.5 (2.3) Turning Radius without Brakes ft (m): 8.5 (2.6) Weight lb (kg): 2101 (955) WHEELS & TIRES: IND [Front/Rear]: 8.5x14 / 12.4x16 CAPACITIES: |
