This Unit is Available and Ready Today – In-Store Purchase Required
Power & Battery
-
Battery: STAR® Smart Lithium, 210Ah
-
Motor: 5 kW AC with thermal protection
-
Controller: 48 V, 450 A
-
Charger: Onboard smart charger (lithium compatible)
Dimensions
-
Overall: 142” L × 51” W × 82.375” H (361 cm × 130 cm × 209 cm)
-
Wheelbase: 96” (244 cm)
-
Ground Clearance: 6.875” (17.46 cm)
-
Wheel Type: 14" × 7" (–43 mm offset) aluminum rims
-
Tire Size: 20×10R14 All Terrain
-
Tire Pressure: 20 psi (138 kPa)
Body & Chassis
-
Chassis: Welded tubular steel
-
Body: Plastic with automotive paint
-
Roof: Plastic, injection-molded
-
Side Rails: Aluminum
Battery Advantage – 210Ah STAR® Smart Lithium
-
Extended driving range for maximum usability
-
Faster charging to keep you moving with less downtime
-
Maintenance-free operation, no watering or servicing required
-
Long lifespan with thousands of charge cycles
-
Environmentally friendly and energy efficient
Performance
-
Passengers: 6
-
Top Speed: 19.5 mph (25 mph if LSV)
-
Turning Radius: 15 ft (4.6 m)
-
Load Capacity: 1,000 lbs (454 kg)
-
Weight (with batteries): 1,600 lbs (726 kg)
-
Drive Train: Direct rear drive, 12.4:1 ratio
-
Brakes: 4-wheel hydraulic (front disc, rear drum) with foot-activated multi-click parking brake
Steering & Suspension
-
Steering Wheel: 3-spoke aluminum, self-canceling
-
Steering System: Self-compensated rack & pinion
-
Front Suspension: Adjustable coil-over shock, independent
-
Rear Suspension: Adjustable coil-over shock
