Serial Number: MBNMCMYADRZB00855
|
ENGINE: Type: Naturally aspirated, water cooled, indirect injection diesel Engine HP [kW] @ RPM: 24.7 (18.4) @ 2900 Maximum Torque (in-lbs) @ RPM: 566 (64) @ 2200 Displacement (in3): 67.2 Number of Cylinders: 3 Firing Order: 1-3-2 Bore & Stroke (in): 3 x 3.2 Compression Ratio: 22:1 Low Idle RPM: 1600 High Idle RPM: 3100 Injection Pump: Denso in-line Accelerator : Hand throttle lever w/cruise knob Muffler: Under hood Air Cleaner: 4" dry Fuel: ULSD Fuel Tank gal (L): 6.6 (25) POWER TAKE OFF: Independent wet clutch PTO Operation: Push button Rear PTO RPM: 540 Mid PTO RPM: 2500 PTO HP [kW]: 17 (10.4) DASH INSTRUMENTS: SAFETY EQUIPMENT: |
DRIVE TRAIN: Transmission: HST two range Number of Speeds: Infinite Clutch: N/A Brakes: Single HYDRAULICS: Type: Open center Steering Pump Output gpm (L/min): 7.3 (27.7) Implement Pump Output gpm (L/min): 3.8 (14.5) 3-Point Hitch: Cat I with telescoping stabilizers Lift Capacity lb (kg): 1100 (500) Optional Fitments: One OPERATOR STATION: FRONT AXLE: |
ELECTRICAL: Battery: 650 CCA, 52 Ah Alternator: 55 A Starter Capacity: 1.7 kW Lights: Projector lamp & LED strip Gauges: Electronic hour meter, stepper gauge for RPM Indicator Lights: Temperature & fuel level DIMENSIONS: Tilt Steering: Yes & telescopic Overall Length in (mm): 100.4 (2550) Overall Width in (mm): 46.3 (1177) Overall Height in (mm): 86.6 (2200) Weight lb (kg): 1573 (715) WHEELS & TIRES: IND [Front/Rear]: 18x8.5-10 / 26x12-12 CAPACITIES: Fuel Tank gal. (L): 6.6 (25) |
